DOWN4SOUND DVX 15" SUBWOOFER - 4 OHM DVC | 1700W RMS
- SKU:
- DVX15D4
Description
Experience unparalleled bass performance with the DOWN4SOUND DVX 15" Subwoofer D4, engineered for audiophiles and car audio enthusiasts who demand powerful, precise sound. This subwoofer features a dual 4-ohm voice coil configuration and delivers a massive 1700W RMS, ensuring your music hits with deep, impactful bass. Its sleek, rugged design not only looks great but is built to withstand high power levels, making it perfect for any car audio setup.
QUICK NOTES:
- RMS OUTPUT: 1700W RMS
- COIL SIZE: 3 INCH
- CUTOUT: 360 mm / 14.17 inches
- MOUNTING DEPTH: 270 mm / 10.63 inches
- WEIGHT: 65 LBS
- Xmax: 33 mm (one-way)
- MOTOR SIZE: 8.66 in - 220 mm | 4.33 inches (Radius)
- Highly extended pole piece for increased linear throw and durability
- Pole vent flared on both ends for superior cooling and low noise
- Extensive rear gap venting to ensure lower coil temperatures
Precision Engineering: Features an optimized motor strength (BL Product: 27.010 T·m) and an effective piston area (Sd) of 73.062 cm² for efficient sound output.
Technical Specifications:
- Revc (DC Resistance): 3.790 Ohm
- Resonance Frequency (Fs): 31.286 Hz
- Total Moving Mass (Mms): 450.940 g
- Suspension Compliance (Cms): 57.388 μm/N
- Equivalent Volume (Vas): 43.500 L
- Sensitivity (SPL): 86.5 dB
- Qms (Mechanical Q): 2.786
- Qes (Electrical Q): 0.461
- Qts (Total Q): 0.395
- Voice Coil Inductance (Le): Not specified but affects impedance rise at higher frequencies.
- Mechanical Resistance (Rms): 0.796
- Ported box volume: 4.5 cubic feet
- Port tuning frequency: 32 Hz
Why You Should Buy:
- Exceptional Performance: Designed for audiophiles who seek deep, precise, and high-quality bass. This subwoofer brings out the best in every beat.
- Versatile Compatibility: The 4-ohm DVC setup allows for multiple wiring options, making it suitable for various car audio configurations.
- Durability and Reliability: Built with premium materials to endure intense sound pressure levels and long-term use without compromising performance.
- Premium Carbon Fiber Dustcap: The real carbon fiber dustcap not only adds a sleek look but also provides extra strength and rigidity for superior performance.
- Optimize Your Experience: Pair this subwoofer with a high-power amplifier to unlock its full potential and ensure clear, powerful bass throughout your vehicle. It's ideal for both daily driving and show setups where exceptional sound quality, and having "mo bass" is a must.
Warranty Information
Warranty Information
Your new Down4Sound product is covered by 1 limited warranty if purchased from Down4Sound or an authorized Down4Sound dealer. This warranty does not cover improper installation, accidental damage, misuse, abuse, improper wiring, operation of unit outside of listed specifications, or any product that has been modified or repaired by anyone other than Down4Sound. Your warranty covers defects in materials and/or workmanship ONLY and is not an insurance policy. The warranty only covers the original owner of the amplifier.
All warranty returns must be accompanied by the original sales invoice or receipt. You must contact us to request an RMA number prior to sending any returns via the RMA request form on our website. You are responsible for the cost of shipping your product back to us for warranty examination. If your product is covered under warranty, shipping back to you will be at no charge to you – if your product is replaced/repaired outside of warranty you must pay for return shipping and repair bill prior to the return of the product or if no defect is found you are required to pay for return shipping only.
At the sole discretion of Down4Sound your product will be either repaired or replaced when it is being covered under warranty. In the event of shipping damage due to improper packaging on products being returned to Down4Sound the customer is liable for the cost of all damages, necessary repairs, or replacement. Be sure to properly pack your return!
* Extended additional warranty purchased on amplifiers take effect from the date of purchase and must also be stated on original sales invoice or receipt.
Refund/Return Policy: https://www.down4soundshop.com/shipping-returns/
Down4Sound - Hours of Operation
Additional Information
Model: |
DVX |
Ohm: |
4 |
Subwoofer Size: |
15 |
Product Type: |
Subwoofer |
Subwoofer Type: |
DUAL VOICE COIL |
